Pro 50w Mini CNC Cutter Router Printer Aluminium Laser Cutting Engraver Machine

Description

ATOMSTACK S10 PRO / X7 PRO / A10 PRO Laser Engraving Cutting Machine

Overview

The ATOMSTACK S10 PRO, X7 PRO, and A10 PRO are advanced laser engraving and cutting machines, differentiated mainly by their colors. These machines are designed for high precision and power, suitable for a variety of engraving and cutting tasks across multiple materials. They feature dual compression spot technology and support offline engraving for added convenience.

Key Features:

• Dual Compression Spot Technology: 50W machine power with 9.5-10W laser output power. Ultra-fine laser focus area (0.08*0.06mm) for high-density laser cutting of 15-20mm thick wood and engraving on mirror stainless steel, ceramics, and glass. Cutting speed is 40% higher than ordinary models.
• High-Performance Fixed-Focus Laser: No need to adjust focus before engraving. The new laser combines precision engraving and high-energy cutting with a focal spot area that is only 1/3 of the spot area of other ordinary lasers.
• Support Offline Engraving: Equipped with a terminal control panel and emergency stop button, allowing engraving work to be done anytime and anywhere without a computer.
• New Filter Panoramic Glass Eye Protection Design: The protective cover filters 97% of ultraviolet light, eliminating the need for goggles and allowing clear viewing of the engraving process.
• Wide Compatibility: Compatible with various mature engraving software, such as LaserGRBL (free) and LightBurn (may require payment), supporting Windows XP/7/8/10/11 and Mac systems. Supports multiple file formats (NC, BMP, JPG, PNG, DXF).

Specifications:

• Model Number: ATOMSTACK S10 PRO / X7 PRO / A10 PRO (same machine, different colors)
• Recommended Print Size: 410*400mm
• Carving Objects: Wood, bamboo, cardboard, plastic, leather, MDF, slate, lacquered metal, mirror stainless steel, etc.
• Cutting Objects: Cardboard, non-woven fabric, veneer, acrylic, some thin plastic boards, sponge, MDF, leather, etc.
• Laser Power: 50W
• Laser Output Power: 9.5-10W
• Wavelength: 445 ± 5nm
• Engraving Accuracy: 0.01mm
• Focusing Method: Fixed focus laser, no need to focus
• Laser Protective Cover: Protects user’s eyes and prevents pets from interacting with the laser spot.
• Operating Software: LaserGRBL, LightBurn
• Support System: Windows XP/7/8/10/11 and Mac (LightBurn)
• Input Format: NC, BMP, JPG, PNG, DXF
• Data Transmission Method: USB connection
• Input Voltage: AC100-240V, 50/60Hz
• Output Voltage: DC12V, 5A
• Package Weight: 6.5kg
• Equipment Size: 600570270mm
• Packing Size: 600350140mm
• Certification: CE, FCC, RoHS, PSE

Additional Features:

• Emergency Stop Button: Enhances safety by allowing immediate shutdown in case of emergencies.
• User-Friendly Interface: 3.5-inch terminal control panel for easy operation and offline engraving.
• Wide Range of Applications: Suitable for a variety of materials and engraving tasks, offering high precision and efficiency.

The ATOMSTACK S10 PRO, X7 PRO, and A10 PRO models provide powerful and precise laser engraving and cutting capabilities, making them ideal for a wide range of professional and hobbyist applications. Their advanced features and user-friendly design ensure high performance and ease of use.
