Industrial Locor A3 DTF Printer, Epson F500 Sublimation & Massive 100x80cm Heat Press Combo

Take your textile production and custom apparel setup to an industrial tier with the ultimate professional printing workshop. This powerhouse commercial bundle combines high-speed Locor A3 Direct-to-Film (DTF) printing, large-format Epson dye-sublimation, and a massive 100x80cm flatbed heat press.

Engineered for serious entrepreneurs and print shops ready to handle large-scale contracts, bulk sportswear production, and high-volume garment personalization across South Africa.

Why Choose This Professional Production Setup?

• Dual-Technology Dominance: Gain the ability to print on absolutely any fabric type or color using DTF, while simultaneously running oversized promotional goods and polyester transfers on the dedicated Epson sublimation line.
• Massive Production Scale: The oversized 100x80cm heat press allows you to cure all-over t-shirt prints, banners, flags, and large fabric panels in a single press cycle.
• Zero Weeding or Pre-Treatment: Eliminate time-consuming cutting and plotters. Print high-detail, vibrant full-color graphics with transparent edges directly onto transfer film.

1. Locor A3 DTF Printer (Dual Epson XP600 Printheads)

The Locor A3 Direct-to-Film printer is a commercial-grade apparel solution engineered with two high-performance Epson XP600 printheads. It delivers rapid, vibrant, full-color transfers onto any garment type without requiring pre-treatment.

Key Capabilities

• Print on Any Fabric: Flawlessly supports cotton, polyester, poly-blends, denim, canvas, leather, and dark or light garments.
• Dual Printhead Efficiency: One head dedicates to CMYK colors while the second head lays down the solid white backing layer simultaneously for fast production speeds.
• What You Need to Run This System: A dedicated computer with RIP software (such as Maintop or Photoprint), DTF transfer film, DTF curing powder, and a heat press. A powder shaker/dryer machine is highly recommended for full workflow automation.

SourcePrinting Quality Warranty & Printhead Care

We provide a limited product warranty on structural machine parts and sub-systems covering manufacturing defects in materials or craftsmanship.

Important Notice on Printheads: The Epson XP600 printhead is a highly sensitive consumable item with a limited lifespan and is vulnerable to voltage fluctuations or lack of regular use. Clogging can occur over time if maintenance is neglected. Therefore, printheads carry no warranty. Complete printhead maintenance training is provided by SourcePrinting during your equipment installation.

High-Priority Daily & Weekly Maintenance Checklist

To ensure your industrial system continues to run smoothly, buyers must adhere to strict maintenance protocols:

• Daily Clean: Gently clean the printheads at the start and end of every single production session using a soft, lint-free cloth and isopropyl alcohol.
• The Daily Print Rule: DTF ink systems require frequent fluid movement. If you do not plan to print daily or run routine test prints, a DTF system may not suit your workflow, and outsourcing your printing may be a safer choice.
• Weekly Ink Flow Check: Deep clean the printhead weekly with specialized DTF cleaning solution. Inspect all ink hoses, dampeners, and capping station connections for air pockets or blockages.
• Monthly Calibration: Perform a comprehensive clean of internal rollers and re-align the printhead mapping to maintain sharp print resolution and prevent color banding.

2. Epson SureColor F500 Large-Format Sublimation Printer

A high-performance, large-format dye-sublimation printer offering unmatched versatility. It seamlessly handles paper rolls up to 610mm wide as well as A3 and A4 cut sheets, making it the perfect tool for expanding into custom gifts, corporate signage, and promotional merchandise.

Technical Specifications

Feature	Description
Printhead Technology	PrecisionCore™ TFP Print Head (Anti-dust design to prevent clogging)
Maximum Resolution	2,400 x 1,200 DPI for ultra-sharp photographic detail
Ink System	Refillable 140ml ink bottles (Can be refilled while the printer is actively running)
Media Formats Supported	24 inch (610mm) rolls, A3 cut sheets, A4 cut sheets
Media Switching	Auto-media switching between roll and cut sheets
Connectivity & UI	USB 3.0, Ethernet, Wi-Fi, and a 4.3-inch color touchscreen panel
Dimensions & Weight	970 x 811 x 245 mm (WxDxH) | 29 kg
Included Softare	Epson Accounting Tool for precise real-time cost-per-print calculations
Manufacturer Warranty	12 Months On-Site Service for complete peace of mind

3. Oversized 100x80cm Commercial Heat Press Machine

Upgrade your workshop’s capacity with a heavy-duty, flatbed heat press engineered specifically for professionals handling large-scale sublimation and curing projects.

Performance & Hardware Features

• Oversized Platen Area: The massive 100x80cm (39.37 x 31.50 inches) printing surface is ideal for banners, flags, curtains, tablecloths, team jerseys, and upholstery panels.
• Premium Cast Aluminum Heating Plate: High-grade aluminum plate construction guarantees uniform heat distribution across the entire surface, preventing cold spots or uneven ink transfers.
• Robust Structural Build: Reinforced heavy-duty steel frame ensures high structural stability and maximum downward pressure during operation.
• Digital Microprocessor Controls: Intuitive control panel for setting precise temperatures up to 250°C and setting accurate countdown timers (0–999 seconds).
• Safety Integration: Outfitted with built-in overheat protection systems and a heavy, heat-insulated handle for daily operator safety.
• Included Accessories: High-density, heat-resistant silicone lower pad, complete operation manual, and optional Teflon sheets for non-stick material protection.

Start Your Commercial Printing Journey Today – South Africa Wide Support

Get the industrial hardware, direct training, and local technical support required to scale your print production. We supply machinery, stock continuous consumables, and provide setup support.

• Showroom Location: Pretoria, South Africa (Private viewing and hardware demonstrations available by appointment only)
• Phone / WhatsApp Support: +27 12 035 1963
• Online Inquiries: Find this complete setup by searching “Professional DTF Sublimation Starter” at www.sourceprinting.co.za for up-to-date quote configurations.
